China En Standard/DIN Standard Cold Rolled Cold Drawn Precise Seamless Steel Pipe with Tolerance /-0.1mm

Product Description

Cold Drawn Seamless steel Pipe with high precision of size
Standard: GB/T8162, GB/T8163, GB/T3639, DIN2391-2
Steel material: 20#(AISI 1020/DIN1.0402 C22), 45#(ASTM 1045,DIN45), 20Cr, Q345B, etc
Technique: Cold rolling
OD: 21mm~416mm
Wall thickness: 0.8mm~20mm
Toleraance of size: ±0.1mm(outer diameter).
Usage: widely used for mechanical processing, Automobile industry, hydraulic equipments
Advantages of our high precision seamless pipe:
1.       Smaller caliber
2.       Accept small qty order
3.       Good surface treatment
4.       The pipe with superior performance, suitable for mechanical making
En Standard/DIN Standard Cold Rolled Cold Drawn Precise Seamless Steel Pipe with Tolerance +/-0.1mm

En Standard/DIN Standard Cold Rolled Cold Drawn Precise Seamless Steel Pipe with Tolerance +/-0.1mm

Chemical Composition

Material	Chemical composition (%)
Material	C	Mn	P	S	Si	Ni	Cu
20# AISI 1020	0.17~0.23	0.35~0.65	≤0.035	≤0.035	0.17~0.37	≤0.3	≤0.25
45# ASTM1045, DIN45	0.42~0.5	0.5~0.8	≤0.04	≤0.045	0.17~0.37	≤0.25	≤0.25

Mechanical Properties

Steel material	Tensile Strength Mpa	Yield strength Mpa	Elongation %	Hardness	Straightness
20#	≥510	≥245	≥25	≤156HB	0.3~1.0
45#	≥647	≥355	≥16	≤HRC62	0.3~1.0
