China Factory Gi Square Tube for Construction
1,Product InformationProduct NameNon-Alloy BS 1387 Hot Dip Galvanized Steel Pipe In ChinaOD20-219mm,WT:0.8-12mmSize10*10-400*400mm,WT:0.8-12mmLength0.3-13m or as your requirementSurfacePre-galvanized/Hot Dip Galvanized/Oiled/PaintedZinc Coating50-150g/m2 for Pre-galvanized,200-600g/m2 for hot dip ga......
Send Inquiry
Product Description
| Product Name | Non-Alloy BS 1387 Hot Dip Galvanized Steel Pipe In China |
| OD | 20-219mm,WT:0.8-12mm |
| Size | 10*10-400*400mm,WT:0.8-12mm |
| Length | 0.3-13m or as your requirement |
| Surface | Pre-galvanized/Hot Dip Galvanized/Oiled/Painted |
| Zinc Coating | 50-150g/m2 for Pre-galvanized,200-600g/m2 for hot dip galvanized |
| Material | Q195/Q215/Q235/Q345/Q195-Q235 |
| Standard | ASTM-A53 /BS 1387-1985/ GB/T 3091-2001 for round pipe |
| ASTM A500 /GB/T3094 for square/rectangular pipe | |
| Ends | Plain /Beveled/ Threaded with sockets coupling and plastic caps/ Necking down/expanding neck/punching holes |
2,Package&Shipping
Packing:In bundle
Loading port: Tianjin,China.
Shipment:usual length ≤5.8m by 20'GP,6m-12m by 40'GP(some sizes with 6m L can be into 20'GP
3.Payment Terms:T/T deposit +BL copy / LC or 100% LC at sight .
4.Delivery Time:Usually 25 days after deposit.
5.Application
Mechanical manufacture, construction field, metallurgy industry, farm vehicles, agriculture
greenhouse, automotive industry, railway, highway guardrail, container frame, furniture,
decoration, steel structure etc.
6.Main Market:Asia,The Middle East,European Union,South Africa and other countries.
| Name | Hot Dipped Galvanized Steel Pipe for Green House |
| Surface | Galvanized (40-60g/m2 usual,can be request by customer) |
| Material | Q195,Q215,Q235 |
| MOQ | 5 tons for normal size and material |
| WT | 0.3-2.2mm |
| Payment terms | TT deposit +BL copy / LC or 100% LC at sight |
| Trade terms | FOB,C&F,CIF,EXW |
| Length | fixed or random,as customer request. |
| End Treatment | Palain(can be threaded,punch,shrink,extension... ) |
| Lead time | within 7 days from stock with 6m length (stock pipe with our factory name in Chinese),20-25 days for customized pipe according to the qty |
2.Product Chemical Composition & Mechanical Properties :
| Grade | Chemical Composition | Mechanical Properties | ||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
3.Product standard test:
| Q195 ≈ | Grade B,SS330 SPHC,S185 |
| Q215 ≈ | Grade C/CS Type B,SS330 SPHC |
| Q235 ≈ | Grade D,SS400,S235 |
| Q345 ≈ | Grade 50/345,SPFC590,E/S335 |
All items of our products and related tests as follow :
1.ERW black round pipe (ASTM A53,GB..)
2.Weld black square/rectangular pipe(ASTM A500,GB,...)
3.Hot dip galvanized round pipe (BS 1387,ASTM A53,GB ,...)
4.Hot dip galvanized square/rectangular pipe(ASTM A500,GB...)
5.Pre-galvanized square/rectangular/round pipe,cold rolled black annealed or bright finished pipe.
6.Spiral steel pipe
7.Seamless pipe (ASTM A53,A106B,)
8.Oval pipe in galvanized and black surface
9.LTZ... special sizes pipe
10.Steel prop , steel plank,steel scaffolding pipe and accessories... steel constrctution material
11.Steel angle, Flat bar,round bar,sqaure bar,
12.H,I,U,C,T,Y,W...steel beam/channel
13.Deformed steel bar
14.Hot rolled& cold rolled steel sheet/coil in black,galvanized,color coated surface.
Product ApplicationField of use and application:
Basic building,Greenhouse construction,High speed fence.Photovoltaic stent,Sports Equipment,ect.
